XT6601 (Discontinued)

XT6601 (Discontinued)

Products Status:     Stock

Type:     Barcode Scanner

Scan Element Type:     CMOS

Colour Depth:     32 Bit

Interface Type:     USB

Max Paper Size:     A4 Size

Optical Resolution:     5mil

Scan Speed:     second

Brand Name:     XTIOT

Model Number:     XT6601 orange

Place of Origin:     Guangdong, China (Mainland)

Interface:     USB,RS-232

Prompt mode Buzzer:     LED indicator

Ambient light intensity:     0~100000 Lux

Scanning range:     QR CODE( 30MIL) 0-20CM, CODE 128 (10MIL) 0-18CM

Product Color:     black,white, or customized colors

Light source:     640*480 CMOS

Application:     supermarket, bank, shopping mall, hospital
Dimensions (W x D x H):     172*71*99mm

Weight:     USB cable 251.5g RS232 cable 258.2g

OEM ODM Service:     Available


0.00
0.00

商品描述

Products Status:     Stock

Type:     Barcode Scanner

Scan Element Type:     CMOS

Colour Depth:     32 Bit

Interface Type:     USB

Max Paper Size:     A4 Size

Optical Resolution:     5mil

Scan Speed:     second

Brand Name:     XTIOT

Model Number:     XT6601 orange

Place of Origin:     Guangdong, China (Mainland)

Interface:     USB,RS-232

Prompt mode Buzzer:     LED indicator

Ambient light intensity:     0~100000 Lux

Scanning range:     QR CODE( 30MIL) 0-20CM, CODE 128 (10MIL) 0-18CM

Product Color:     black,white, or customized colors

Light source:     640*480 CMOS

Application:     supermarket, bank, shopping mall, hospital
Dimensions (W x D x H):     172*71*99mm

Weight:     USB cable 251.5g RS232 cable 258.2g

OEM ODM Service:     Available


Durable handheld waybill barcode scanner for tracking

Barcode Sensitivity

Tilt ±60° @ 0°Roll and 0° Skew

 Rotate 360° @ 0°Pitch and 0° Skew

 Deflection ±55° @ 0°Roll and 0° Pitch

Reading code system

1D Code 128, UCC/EAN-128, AIM 128, EAN-8, EAN-13, ISSN, ISBN, UPC-E, UPC-A, Interleaved 2 of 5, ITF-6, ITF-14, Matrix 2 of 5, European 25, Standard 25, Code 39, Codabar, Code 93, Code 11, Plessey, MSI-Plessey, RSS-14, RSS-Limited,

RSS-Expand

2D PDF417,Data Matrix,QR,Micro QR
Electric Current Maximum Current <180mA
Operating Current 150mA±15mA
Standby current

120mA±2mA

Operating temperature

-20°C~50°C

Storage temperature

 -40°C~70°C

Operating temperature -20°C~50°C
Relative humidity 5%~95% (non-condensing)
Storage temperature -40°C~+70°C
Features Quickly and accurately identify one-dimensional codes and two-dimensional codes, No plug-in, lightning invoice, Various Applications: Supermarket/convenience store cashier, customer service counter, ticket window, O2O application site, etc.
