Drug electronic supervision code, referred to as drug supervision code, is an electronic identification used to provide information services such as identity verification, information storage and collection, and logistics flow statistics for drugs.

The drug supervision code is encoded by 20-digit numbers, which is embodied in the form of Code 128C 1D barcode and digital characters, and supports automatic identification equipment and human eye reading.

The drug simplification code is divided into the first-level drug supervision code (the smallest sales package of the drug), the second-level drug supervision code (the inner packaging of the drug), and the third-level drug supervision code (the outer packaging of the drug, and so on), which are used to identify the smallest sales package respectively Drugs, intermediate individually packaged drugs, and outer cartons of individually packaged drugs.

Application scope of drug supervision code

The drug supervision code is applied to the modern drug information management method of real-time monitoring of drug production, circulation, and inventory through the use of coding technology and network technology, through "one piece" and "whole process verification, registration and write-off".

2. Drug supervision code coding standard

The 20-digit number of the drug supervision code is encoded using the Code 128C encoding standard, and it can be calculated that the barcode symbol is composed of 145 modules, that is, 145X.

2. The form of drug supervision code

In order to meet the needs of packaging in different shapes, manufacturers can choose one of them according to specific conditions.

3. Drug supervision code coding rules

The drug supervision code uses a 20-digit code, of which the first 7 digits (product resource code) contain information such as enterprise information, drug discovery ability, dosage form, approval number, packaging specifications, etc., which is convenient for data storage and can be applied to logistics and retail settlement. use.

The 8 to 16 digits of the drug supervision code are the serial number of a single product, and the last 4 digits are the check digit, which is generated by a special encryption algorithm.

4. Drug monitoring code capacity

Due to the independence of the drug supervision code coding method, it can fully support a large number of drug varieties and code capacity.

The above is the introduction of the coding standard and application scope of the drug electronic supervision code, the printing direction of the drug supervision code and the size of the blank area of the drug supervision code, you can go to the barcode printing software to find the corresponding tutorial, and the production of the electronic supervision code can refer to: How to make electronic supervision code in barcode printing software.
