Q: What is the XT6202MRZ?

A: The XT6202MRZ is a wireless handheld 2D barcode scanner specifically designed to read passport MRZ (Machine Readable Zone) codes, ID card MRZ codes, and standard 1D/2D barcodes .

Q: What type of passport codes can it read?

A: It reads passport OCR codes (MRZ), including 2-line passport MRZ and 3-line ID card MRZ formats. It is ICAO 9303 compliant and reads passports from countries including Russia, UK, US, Germany, France, Italy, and 40+ more .

Q: How fast is the recognition speed?

A: Recognition speed is 0.3 seconds per scan – over 10 times faster than manual entry .

Q: What is the image resolution?

A: It features a 1280×800 pixel megapixel CMOS image sensor .

Q: What barcode formats does it support?

A:

1D codes: Code128, EAN-13, UPC, Code39, Codabar, GS1 DataBar, ISBN, ISSN, ISBT 128, etc.

2D codes: QR Code, Micro QR, Data Matrix, PDF417, Aztec, MaxiCode, Hanxin

Q: What is the scanning accuracy?

A: Accuracy is ≥3mil for high-density codes .

Q: How does it connect to devices?

A: It supports Bluetooth 4.0, 2.4G wireless (with USB dongle), and USB wired connection . Works with Android, iOS, Windows, Linux, and MAC OS .

Q: What is the wireless transmission distance?

A: In open space: 2.4G up to 100 meters, Bluetooth up to 50 meters .

Q: Does it have built-in storage for offline scanning?

A: Yes. It has 16MB memory that can store approximately 130,000 barcode records (EAN13 product codes) for offline scanning, auto-sync when reconnected .

Q: What is the battery life?

A: 2000mAh battery. Normal working time is greater than 8 hours; continuous scanning can exceed 80,000 scans per full charge .

Q: Is it plug-and-play?

A: Yes. Under USB port, it supports USB-keyboard mode. No driver needed for basic operation .

Q: Can I customize the output format?

A: Yes. Support adding up to 10 characters as prefix or suffix. Baud rate adjustable from 9600 to 115200 .

Q: What scan modes are available?

A: Manual trigger mode, induction mode (auto-sensing), continuous mode, and storage inventory mode .

Q: Where is it commonly used?

A: Airport immigration and boarding gates, hotel check-in, car rental services, currency exchange counters, event security, and government ID verification .

Q: Is it suitable for outdoor use?

A: It works under sunlight (0–100,000 Lux), but is NOT waterproof. For outdoor use, add a protective cover .

Q: What is the working temperature range?

A: -20°C to +50°C (operating); storage temperature: -40°C to +60°C .

Q: What are the dimensions and weight?

A: 72.7(W) × 102.7(D) × 162.5(H) mm. Weight: 201g .

Q: Does it support SDK?

A: Yes, SDK is available for custom integration .

Q: Does it support OEM customization?

A: Yes. Custom logo, custom packaging, and custom cable available. Private mold design .

Q: What is the warranty?

A: 1-year warranty with lifetime technical support .
