What Are CAD Drawings?

CAD drawings (2D and 3D files) contain the complete dimensional specifications of a scanning module, including length, width, height, mounting hole locations, and interface positions. When suppliers provide these drawings, engineers can perform structural design and space verification before ordering, ensuring the module fits perfectly into the intended device without costly redesign iterations.

XTIOT Products with CAD Drawing Support

XTIOT provides comprehensive 2D drawings and 3D files for their scanning modules, enabling seamless integration into OEM devices.

XT206M1 Mini Barcode Scanner Engine

The XT206M1 is an ultra-compact mini scan engine designed specifically for integration into mobile payment systems and smart shopping cart tablets . With its corrosion-resistant metal body, it offers durability while maintaining a lightweight form factor. XTIOT provides complete dimensional documentation for this module, allowing engineers to validate fit before production .

Perfect for:

• Smart shopping cart tablets – engineers can verify module placement within the tablet housing

• Mobile payment terminals – confirm fit in slim handheld devices

• Retail checkout systems – integrate into compact countertop units

• OEM device manufacturing – ensure proper clearance and mounting alignment

XT2003C / XT2003D Series Fixed-Mount Scanners

The XT2003C and XT2003D fixed-mount scanners are designed for integration into production lines, logistics systems, and pharmaceutical traceability applications . These modules feature multiple interface options including USB, RS232, and TTL, with compact dimensions that facilitate installation in conveyor systems and sorting stations . CAD documentation is available to support system integration planning.

Perfect for:

• Pharmaceutical packaging lines – validate scanner placement relative to moving vials

• Logistics sorting stations – confirm mounting position on conveyor frames

• Tobacco and alcohol traceability systems – ensure proper alignment with production equipment




XT206H1 Adhesive-Mount Module

The XT206H1 features a 3M double-sided adhesive ring around the scanning window edge, enabling quick attachment directly to device panels . XTIOT provides dimensional drawings showing the adhesive ring placement and overall module footprint, allowing engineers to plan panel cutouts and mounting surfaces.

Perfect for:

• Thin-panel device integration – verify panel thickness and adhesive contact area

• Quick retrofit installations – confirm clearance behind existing panels

• OEM enclosure design – ensure proper window alignment with module lens

XT2001CM / XT2001DM Split Design Modules

The XT2001CM and XT2001DM feature 1.5mm stamp hole design for direct SMT soldering onto POS motherboards . Their split core board and lens architecture enables ultra-thin product designs . XTIOT provides detailed PCB layout drawings and 3D models to support motherboard integration and component placement.

Perfect for:

• POS terminal manufacturing – verify component placement on motherboard

• Ultra-thin device production – confirm split placement of board and lens

• High-volume automated assembly – validate SMT pick-and-place positioning

XT206M3 Fixed-Mount Scanner

The XT206M3 is designed for fixed-mount applications in self-checkout kiosks, vending machines, and POS devices . With compact dimensions, it can be securely installed using standard mounting methods. CAD documentation supports integration planning for these fixed-position applications.

Perfect for:

• Self-service kiosks – verify scanner placement within kiosk housing

• Vending machines – confirm mounting position for reliable scanning

• Hospital pharmacy systems – ensure proper integration with existing equipment

Critical Applications Requiring CAD Drawings

How XTIOT Supports Structural Design

2D Drawings

XTIOT provides 2D dimensional drawings showing:

• Overall length, width, and height

• Mounting hole locations and sizes

• Interface connector positions

• Optical window dimensions

• Clearance requirements

3D Models

XTIOT provides 3D files (STEP, IGES, or STP formats) that engineers can import directly into CAD software for:

• Virtual assembly verification

• Interference detection

• Thermal and mechanical simulation

• Enclosure design validation

Application Notes

XTIOT supplies detailed integration documentation including:

• Recommended mounting methods

• PCB layout guidelines for stamp hole models

• Optical window design requirements

• Environmental protection considerations

Why CAD Drawings Matter for Integration

Without accurate CAD drawings, engineers face:

• Space miscalculations – module may not fit in intended location

• Interference issues – components may collide with other hardware

• Mounting alignment problems – screw holes or windows may misalign

• Costly redesign – enclosures may need re-tooling after discovery

• Production delays – integration issues discovered late in development cycle

XTIOT delivers this capability by providing comprehensive 2D drawings and 3D files for all scanning modules, enabling engineers to validate designs virtually before committing to production.

Ensure your device design fits perfectly from the start. Contact XTIOT today for 2D drawings, 3D files, and integration support tailored to your project.
