The user handles the substandard products to reduce the amount of substandard products in the warehouse. Users can return unqualified products to the workshop for processing and maintenance, and then store them as qualified products; or sell unqualified products to unqualified product acquisition companies.

12. Barcode management

Barcode Rule Definition

Barcode Rule Assignment

Generation of barcodes

Collector settings

Generate documents in batches

Multi-dimensional analysis table and report query function

1. Inquiry about the current inspection volume

2. Inbound and outbound flow account

3. Inventory ledger

4. Shelf life warning

5. Inventory Outlook

6. Send, receive and store summary table

7. Inventory age analysis

Barcode Scanner Hardware Device

Wireless barcode scanner, ring bluetooth barcode scanner, barcode reader module, etc.

XT6400, XT3001ER, XT2003C.

Barcode Printing Solutions

According to the specific needs of different customers for barcode (label) printing, Sutongda has organized the following specific solutions for label printing, as well as several recommended products, there must be one suitable for you!

1. Thermal transfer barcode label printing

The principle of thermal transfer printing technology is to melt and transfer the solid ink on the ribbon to the medium by heating and pressing to complete the label printing. By selecting the thermal transfer ribbon to match the label material, the thermal transfer printing method can produce barcode labels with special properties such as high temperature resistance, abrasion resistance, chemical solvent resistance, etc. Therefore, it is the most widely used in the barcode industry. The precision of thermal transfer printers is 203DPI, 300DPI, 406DPI and 600DPI. Printing speed from 51mm/sec to 300mm/sec. Label printing widths are usually 71mm, 104mm, 165mm and 215mm.

2. Thermal barcode label printing

The thermal printing method uses thermal label material, does not use ribbon, and directly heats the thermal label to complete the printing. Thermal barcode labels have a short lifespan. Usually the label storage time does not exceed six months, and they are mainly used indoors or where the ambient temperature is not high. Barcode label printer using thermal technology at lower cost. However, the consumption cost of the print head is relatively high. Mainly used in special fields such as retail.

3. Product packaging label printing solutions

Barcode label printing for product packaging is the most widely used occasion for barcode label printers. Packaging labels are usually large in size, require low printing accuracy, and have a large printing volume. Most of the label materials are paper materials, and the ribbons are mostly ordinary wax-based or mixed-based. Therefore, it is more suitable to choose a low-precision industrial-grade barcode printer.

4. Product nameplate label printing solution

Product nameplate labels are commonly made of synthetic materials such as PET; the ribbons are also mainly made of pure resin, and mixed ribbons can also be selected. To ensure various performance requirements and durability of barcode labels. In the layout design of product nameplate labels, it is often necessary to print company logos, special symbols and graphics. The printing of characters, especially Chinese characters, is also required to be as beautiful as possible. Therefore, high-precision thermal transfer printers are selected.

5. Precision positioning printing solutions

The mechanical positioning accuracy of ordinary thermal transfer barcode label printers is only 13 mm. It is difficult to meet the printing requirements of small labels such as circuit board labels, chip labels, jewelry labels, etc. At this time, a printer with precise label positioning is required. The precision positioning barcode printer is a special thermal transfer barcode label printer designed to meet this need.

In addition, some labels have a lot of content in the layout. If the positioning is not accurate, the printed content may drift out of the label layout. At this time, a barcode printer with precise image positioning function is required to ensure that the range of image drift during mass printing is within the allowable error.
