XTIOT Scanners for Laboratory Workflow
XTIOT offers reliable scanning hardware for reagent tracking and experiment data linkage in research and analytical laboratories.
🔹 XT8001D – Lightweight PDA for Reagent & Record Binding
The XT8001D is a compact Android handheld PDA (288g) perfect for scanning reagent codes and experiment record codes, linking them for full data traceability .
| Feature | Specification |
|---|---|
| OS | Android 15.0 |
| Screen | 4.0" HD touch |
| Weight | 288g – lightweight for lab use |
| Barcode reading | 1D + 2D (QR, Data Matrix, PDF417) |
| 4G/WiFi | Real-time data sync |
| Battery | 5050mAh |
| IP rating | IP65 dustproof and waterproof |
Use for: Scanning reagent barcode + experiment record barcode, linking formula data to results, recording technician name and preparation time.
🔹 XT8601B – Batch Scanner for Mix Components
The XT8601B is an industrial fixed scanner with batch reading capability, perfect for scanning multiple mix components at once .
| Feature | Specification |
|---|---|
| Batch scan | Up to 100 codes per trigger |
| Read speed | 90 codes per second |
| Multi-code reading | Scans 2+ barcodes in one pass |
| Accuracy | 99.7% at high density |
| IP67 | Dustproof and waterproof |
Use for: Scanning all mix component codes in a single pass for formula preparation, component ratio verification.
🔹 XT3001BHD – Hands-Free Ring Scanner
The XT3001BHD is a wearable Bluetooth ring scanner for hands-free lab operation .
| Feature | Specification |
|---|---|
| Type | Wearable Bluetooth ring scanner |
| Scan speed | 300 scans/sec |
| Resolution | ≥3mil |
| Storage | 130,000 barcode records |
| Battery | 8+ hours continuous |
Use for: Scanning reagent codes while handling glassware, hands-free mix component verification.
Laboratory Workflow Scanning
Workflow 1 – Reagent + Experiment Record Binding
Technician scans reagent barcode using XT8001D
↓
Technician scans experiment record code
↓
System links: reagent batch, lot number, expiry → to experiment data
↓
Technician records: name, date, experiment ID
↓
Full traceability achieved
Workflow 2 – Mixed Reagent Preparation
Technician scans each mix component barcode
↓
XT8601B batch scans up to 100 component codes in one pass
↓
For smaller mixes: XT3001BHD ring scanner for individual components
↓
System records: component names, batch numbers, ratios
↓
Technician enters: mixer name, preparation time, final volume
↓
Inventory updated for each component used
Efficiency Gains
| Task | Manual Process | With XTIOT | Improvement |
|---|---|---|---|
| Mix component logging | Manual entry per component (2-3 min) | Batch scan (2 sec) | 98% faster |
| Reagent-experiment binding | Paper log (1-2 min) | Scan binding (5 sec) | 90% faster |
Recommended Setup
| Laboratory Type | Recommended Scanner |
|---|---|
| Routine reagent tracking | XT8001D PDA |
| Mix formula preparation | XT8601B batch scanner |
| Hands-free lab operation | XT3001BHD ring scanner |
Need a laboratory reagent and experiment record scanning solution? Contact XTIOT for the right recommendation.
